Mini Regulator
Features
- Balance valve design with non rising regulating knob and locking ring.
- Diaphragm operated regulators provide more precise pressure control than piston type.
- Minimizes secondary pressure Fluctuation.
- Maximum primary range 0 - 260 PS.
- Secondary Pressure range 0 - 150 PSI
Size Model
| Port Size | Model No. |
|---|---|
| G1/4" | FSMI-2 |
| Thread Options | NPT/ BSP (F) |
Siemag Miniature Series Regulators are designed to provide minimum pressure drop over a wide operating range - two full flow 1/8" gauge ports can be used as secondary outlet ports.
Built in self releaving feature protects system components from over pressurizing of downstream air, permitting pressure adjustments in dead end circuits.
Material
| Body | Pressure Die Cast Aluminium |
| Size | 1/4" NPT/BSP (F) |
| Bonnet | Plastic |
| Temperature | 0-60°C |
| Max Pressure | 10 kg/cm2 (18 kg/cm2) |
| Input Pressure | 10 kg/cm2 |
| Output Pressure | 0-10 kg/cm2 (Adjustable) |
| Net Weight | 135 (approx) |
| Knob | Plastic (Locking Type) |
| Diaphragm | Nitrile |
| Type | Relieving (Optional-Non Relieving) |
