Features
- Exceptional compactness & economy
- Same high level performance of individual filter & regulator
- Saves space, reduces pipe connections & costs less
- Full flow gauge port
- Choice of automatic drain
- Built-in relief
- Non-threaded bowl
- Quick release bayonet, bowl & guard assembly
- Non-rising low torque pressure adjusting knob
- Push-pull adjusting knob
- Flow sensor provides a constant oil/air ratio over a wide range of flows
- Oil filling under pressure possible
TECHNICAL DATA:
| Medium |
Compressed air & non-corrosive gasses. |
| Maximum Operating Pressure |
10kg/cm2 |
| Ambient Temperature |
50° C |
| Secondary pressure range |
0-2, 0-4, -7, 0-10 kg/cm2 |
| Relieving type |
Standard |
| Non - Relieving |
Optional |
| Drain |
Manual or Automatic |
Material :
| Body |
Pressure Die Cast Aluminium |
| Element |
Polyproplene (Optional - Sintered Bronze) |
| Deflector |
Plastic |
| Plain Baffle |
Plastic |
| Seals |
Nitrile |
| Bowl |
Polycarbonate (Optional - Metallic) |
| Size |
1/4", 3/8", 1/2" NPT / BSP / BSPT |
| Bonnet |
Plastic |
| Temperature |
0-60°C |
| Bowl Capacity |
130 ml |
| Max Pressure |
10 kg/cm2 (18 kg/cm2 with metal bowl) |
| Output Pressure |
0-10 kg/cm2 (Adjustable) |
| Net Weight |
610 (Approx) |
| Working Pressure |
0-10 kg/cm2 |
