3/2 Way Direct Acting Midget Solenoid Valve
3/2 Way Direct Acting Midget Solenoid Valve (NC/NO)
Features
- Tight shut-off
- No Minimum Pressure required.
- Low Cost - Minimum size.
- Only one moving part eliminates maintenance problem
- To control instrument air, low pressure gases,
- Gravity feed & other applications.
- Can be installed in any direction.
Automatic Solenoid valves may be used to Contrrol Instrument air. High pressure gases gravity feed and other applications where Minimum size & Low cost are decisive factors.
Typical installations of shut Off / Laundry Equipments Spraying Equipment / Dental equipment / Health Clubs / Water Taps / Urinals / Boiler applications Providing automatic solutions to all manual process
TECHNICAL DATA:
| Type | Normally close & Normally Open |
| Orifice | 1 mm to 6 mm |
| Working Pressures | 0 - 50 bar (Wk. Pr. for 6 mm orifice - max 2 bar) |
| Coil | Class A Standard Optional Class F (150 Deg) / Class H (180 Deg) |
| Wattage | 4.5 to 11 W |
| Enclosure | IP 55 / IP 65 / IP 66 / IP 67 |
| Size | 1/8" & 1/4" 3/8" & 1/2" |
| Threads | BSP / NPT |
MATERIAL OF CONTRUCTION:
| Body | Forged Brass & stainless Steel 304 / SS 316 |
| Housing | Brass Stainless Steel |
| Plunger | SS 430 F |
| Spring | SS |
| Seals | Buna - N Standard (For High Temperature Viton / Teflon) |
