Astra Lubricator
Features
- Compact design
- Flow sensors provides a constant oil/air ratio over a wide range of flows
- Proportional delivery design prevents tool starvation or flooding
- Simple know type oil feed control
- All round 360 Deg visibility of sight glass
- Oil filling under pressure possible
- Quick release bayonet, bowl, and guard assembly
Size Model
| Port Size | Model No. |
|---|---|
| G1/4 | ASF-2 |
| G3/8 | ASF-3 |
| G1/2 | ASF-4 |
ACCESSORIES
Mounting bracket with screws
The Siemag Astra Series Lubricator provides a constant oil- air ratio over a wide range of flows. The proportional delivery design prevents tool starvation or flooding. Other features such as the 360 degree visibility from the sight glass, dial set adjustments, double fill ports and online oil filling under pressure make the Astra Series Lubricator the favourite in its category.
The quick release bowl assembly make it easier to fill oil in the lubricator bowl directly making it the best for any in-plant or OEM application.
Material
| Body | Pressure Die Cast Aluminium |
| Seals | Nitrile |
| Bowl | Polycarbonate (Optional - Metallic) |
| Size | 1/4", 3/8", 1/2" NPT / BSP / BSPT |
| Temperature | 0-60°C |
| Bowl Capacity | 130 ml |
| Max Pressure | 10 kg/cm2 (18 kg/cm2 with metal bowl) |
| Net Weight | 410 (approx) |
| Working Pressure | 10 kg/cm2 |
| Sight Glass | Polycarbonate |
