Mini Combination
Features
- Excellent water removal efficiency.
- Space saving package offers both Filter & Regulator features in one integral unit.
- Non rising adjustable knob and locking ring.
- Two full flow 1/8” gauge ports.
- Easily disassembled for servicing without the use of tools.
- Manual drain allows quick and easy removal of fluids and particles.
- Bowl capacity 1.5 oz.
- Optional panel mounting ring & bracket available.
Size Model
| Port Size | Model No. |
|---|---|
| G1/4" | FRSMI-2 |
| Thread Options | NPT / BSP / BSPT |
Siemag miniature series combination combines the fine features of Mini Filter and Regulator into a compact space saving unit. Designed to provide minimum pressure drop over a wide operating range.
Two full flow 1/8” gauge ports can be used as secondary outlet ports.
Material
| Body | Pressure Die Cast Aluminium |
| Element | Polypropylene |
| Deflector | Plastic |
| Plain Baffle | Plastic |
| Max Pressure | 10 kg/cm2 (18 kg/cm2 with metal bowl) |
| Input Pressure | 10 kg/cm2 |
| Seals | Nitrile |
| Bowl | Polycarbonate (Optional - Metallic) |
| Size | 1/4" NPT/BSP (F) |
| Bonnet | Plastic |
| Temperature | 0-60°C |
| Bowl Capacity | 40 ml |
| Output Pressure | 0-10 kg/cm2 (Adjustable) |
| Net Weight | 162 gm (approx) PC Bowl / 200 gm (approx) Metal Bowl |
| Working Pressure | 0-10 kg/cm2 |
