Mini Filter

Features

• Excellent water removal efficiency.
• Non corrosive polyproplene filter element (Optional - Sintered Bronze).
• Unique deflector plate creates swirling of the air stream ensuring maximum water and dirt separation.
• Easily disassembled for servicing without the use of tools.
• Manual drain allows quick and easy removal of fluids and particles.
• Bowl capacity 1.5 oz

Size Model

The Siemag Miniature Series Filter are designed for application where space is limited and demanding high filtration efficiency in removing airborne solid contaminants, pipe scale, rust, pipe dope, etc. Which may plug small orifices or cause excessive wear and premature failure of pneumatic components.

Material
