B55 Needle Valves
Siemag makes these pressure needle valve for suitable pressure up to 15000 PSI.
FEATURES:
- Heavy duty
- Integral bonnet
- Positive shut valve
- Compact body
- Stainless steel stems
- Excellent metal-to-metal seat
Size Model:
| MODEL NO. | SIZE |
|---|---|
| B/S4/S6-55-HP-(ST/AN)-M4 | 1/2” NPT/BSP |
| B/S4/S6-55-HP-(ST/AN)-F4 | 1/2” NPT/BSP |
| B/S4/S6-55-HP-ST/AN-FM4 | 1/2” NPT/BSP |
HOW TO ORDER :
- Select Prefix B for BRASS, S4 for SS304 & S6 for SS316
- Select Prefix ST for STRAIGHT PATTERN & AN for ANGLE PATTERN
- How to Order : If your requirement is of 1/2” Needle Valve Straight Pattern with Female connection in Brass. Your corresponding Model No. is B-55-HP-ST-F2.
Also available with hardened floating tip for maximum seat life.
| Body | Forged Brass & forged Stainless Steel |
| Size | 1/2" Male, Female, OD Tubing & Female to male connection |
| Pressure Range | Upto 200 Bar (For High Pressure contact HQ) |
| Pattern | Straight |
| Teflon | PTFE |
